MASH Steel All-Road Frameset

Wednesday April 27th at 9:00 AM Pacific time, we will offer our first steel road framesets at shop.mashsf.com. We have been developing this model for years, getting feedback, adjusting, and we are ecstatic with the results. Framesets are spec’d with our butted steel, phosphate dipped, and sprayed with a matte clear finish, with gloss clear artwork. Check the notes below, and email info@mashsf.com with any questions you may have. We ship worldwide from San Francisco. If you are in Japan, please check with Blue Lug Tokyo!
Includes our frame, fork, front and rear axles, collar, cable guides, and hanger. A size large frame weights 5lbs, and the fork with cut steer weighs 2lbs.
Clears 700-35+ 650-42+
Detail of our cast fork crown creating a 1 1/8 370/43 straight blade, thru axle steel fork
Note: This sample had internal rear brake, but we updated it to be fully external, developing new cable guides to support up to 3 cables. Front and rear derailleur, and rear brake.
We now offer these rack struts in matte black if you are looking for a mid fork strut solution for our rack.

MASH AC-3 Frameset in Smoke 2022

We are excited to share our AC frameset for 2022. For the third installment in this series, we updated our monocoque carbon fork to clear 32c 700c tires on a wide rim. It’s the only 30mm rake carbon track fork, that’s why we own the mold on this unique design. We use Columbus Airplane tubing, phosphate dip the frames, smoke, decal, and clear coat the finished aluminum.
Framesets include our zero stack headset, seat collar, compression plug, and top cap. Framesets are available in 6 sizes, and retail for $925.00 USD. Available Wednesday April 6th at 9:00 AM Pacific time at shop.mashsf.com
Specs include: 27.2 post, English 68 bottom bracket, 100/120 hub spacing, Tapered 1 1/18 to 1 1/2 head tube, headset included.
Stainless dropout plates are marked for symmetry, and chain stay length.
This build is size 56 Large, and weighs under 14lbs. The frame + Fork, headset, and collar weigh under 5lbs total.
Both the fork, and the rear brake bridge are designed to look clean, but both can be drilled to support caliper brakes.

MASH Hardtail 2022

Excited for this day! It’s no surprise we have cheered for single speed bikes for 17 years, and that love will NEVER stop. We have also had more than one discipline of bike, whether it was a track bike, bmx, cx, road, gravel, and mountain. Part of what keeps bike people happy for life is being able to jump between a few formats of machines. For 2022, we are sharing our first geared frames, including our hardtail.

This frame is in the middle between XC and Aggressive bikes, a great trail hardtail nicknamed the Rockbanger.

It’s made from double butted 4130 steel, built to not be the lightest bike, but supple and super fun. Born partly from bmx brains, and you can see it all the way down to the gussets. It’s as simple as these bikes get, and can use the Phil Wood Eccentric BB if you want to run it as a single speed.

We chose specs that would make it really accessible to build up. English bb, 31.6 post, boost spacing, tapered headset.
Enclosed are some details for our first Hardtail release Wednesday March 23rd at 9:00 PST.  at mashsf.com

Suggested sizing, but you may prefer a bit bigger or smaller frame.


XS: 4’11 to 5’3  or 149.86cm to 160cm
S: 5’3 to 5’8 or 160cm to 172.7cm
M: 5’8 to 5’11 or  172.7cm to 180.3cm
L: 6ft to 6’2  or 182cm to 187cm
XL: 6’3 to 6’5  or 188cm to 195.5cm

XS – L are built for 130-140 travel forks.
XL is a 29r, built for 120-130 travel forks.
Or you can build it rigid with a travel adjusted carbon or steel fork.
The frames are $925.00 in the US, and also available at Blue Lug Japan.

The Raw frames are treated with a phosphate solution to slow rusting, and then sprayed with matte clear. Shown with a Chris King Inset 2 headset. Headsets are sold separately.


31.6 Internal Dropper length suggestions:
XS- up to 150 mm dropper
S up to 175 mm dropper
M: up to 200 mm dropper
L: up to 230 mm dropper
XL: up to 240 mm dropper

The bike is compatible with 2.3 to 2.6 27.5 tires depending how you want it to feel. We have been loving 2.4 27.5 on them. The XL hardtail will fit up with similar width tires.

John Benett on the wall. All photos by Kyle-Emery Peck @instacubs

MATT REYES STEEL FRAMESET 2022

-
THE MATT "SLUMWORM" REYES SIGNATURE FRAMESET
-
-
INTRODUCTION:
Hey there, Matt Reyes here. MASH gave me the keys to the car and let me make this blog post. I’m currently writing to you from my 4th floor studio apartment here in San Francisco. My cat says hi. A little more than a year ago, MASH approached me with the opportunity to collaborate and produce a signature frame set.

I had been in love with the MASH steel frame for quite some time. It was a strong bike, with a great geo, cleared huge tires and had the ability to bar spin with a slightly longer fork. (An absolutely crucial feature) We took that frame as a solid foundation and evolved it into what you see here.

You might be asking. What did we update? ¯\_(ツ)_/¯

In this post I'll point out and elaborate on the 6 major changes we made to the frame. Our thought process, reasonings and the sub sequential performance advantages these subtle tweaks made to the overall feel of the ride.
-
-
THE FORK:
The transformation began with prototyping a couple different fork options before landing on what you see here. We went with a 420AC fork with shorter (29mm) dropouts than standard (referencing the Fumanchu fork as an example). The shorter fork dropouts keeps the wheelbase tight while giving you additional bar spin clear as your wheel spins back towards your feet. The tapered tube design for the fork arms keeps the aesthetic looking more track bike while minimizing the amount of weight on the front end. This slight shaving in weight provides huge advantages when doing spin tricks and throwing the bike around.
-
-
TUBING:
MASH Butted Steel. For this frame we used more BMX style tubing that is larger in diameter for both the top tube and down tube. The top tube angle has also been dropped as it descends to the seat tube. Making it easier to get more height out of bunny hops and allowing you to drop your knee over the bike. Which has its advantages when it comes to control and performing certain tricks.

HEADTUBE:
The head tube was updated to an hourglass shape that utilizes drop in bearings instead of press fit. Just one more thing that makes working on and maintaining your bike easier from the comfort of your own home. Less is more, especially when it comes to the amount of tools you need to assemble.
-
-
THE TOP TUBE:
One of the key focuses of the project was establishing greater bar spin clearanace. We achieved that by extending the top tube a touch and providing less toe overlap. All of which helps whether you’re doing tricks or just riding around town. It was intended to be run with a shorter stem. Bringing your bars closer to you and giving the bike more BMX handling feels. If you want the same body position you had on your “Steel Frame” I recommend you run a stem that’s 10-20mm shorter.
-
-
GUSSETS:
There are 3 primary gussets on the REYES Steel Frame. They’re located on both the top tube and down tube, reinforcing the connection point to the head tube. The third gusset is a small bridge that is tucked away behind the BB giving the chain stays additional strength and lateral support.

TIRE CLEARANCE:
I’ll be honest. The first thing that drew me to the MASH Steel frame was the huge tire clearance it offered. With this frame set we attempted to provide even more space. Just incase your tires get a little wiggly and out of true. The drive side chain stay features a solid steel plate that gives space for a 42-45c tire while still providing room for a full size chainring.
-
-
ADVANTAGES
-
-
IMPORTANCE OF SPEC:
If you’re like me and replaced the fork on your MASH Steel frame for something longer, then I’m sure you noticed that the bike handled entirely different once you made that change. The handling on it somehow felt a little more squirley and unpredictable. Things are designed the way they are for a reason and the REYES Steel frame is designed around a 420AC fork. Making the ride feel a heck of a lot more locked in and controllable. Riding through traffic no hands is now easier than ever.

BB HEIGHT:
The BB height on this bike is relatively high, yet low enough to feel stable while pedaling out wheelies. Once you put some 38-42c tires on, it boosts the bike so high off the ground that you effectively eliminate the threat of pedal strike all together. I’m able to lean into corners so deep on this bike. It’s absolutely insane. That coupled with some knobby tires make this bike a cornering monster.
-
-
FEATURES YOU WON'T SEE:
A couple of the things that this frame doesn’t have in comparison to the MASH Steel Frame are the water bottle mounts, brake mounts, and brake cable routing holes going through the top tube. Less is more. Especially if you’re going to be jumping off a bunch of stuff. Haha.

FEATURES WE KEPT:
Again, using the MASH Steel frame as our base, we kept most of the same component spacings and sizes. That way swapping over parts from your existing track bike will be a breeze without having to gather different or additional components.

WHAT DOES THE BIKE COME WITH?
Beyond just coming with a Frame + Fork, the full package includes headset bearings, a MASH seat post collar and a MASH top cap assembly. We did our best to provide everything you'll need to get up and running.
-
-
CLOSING STATEMENT:
That’s about all I have for you right now. I couldn’t be more stoked on how this project turned out and feel incredibly blessed to be a part of it. That being said, it’s 3:21am here in San Francisco and I should probably wrap things up for the night. I haven't proof read any of this, but whatever. Whether you read everything or scrolled quickly, you made it this far, go ahead and give yourself a high five. You crushed it. Thanks for being here and we’ll see you out there.

Be good, have fun and we’ll talk more soon.
-
-
Photos By: Mike Martin // Spenser // Matt Reyes
-
-
:)

MASH Steel Frames 7-21

Enclosed are notes for our 2021 steel frame delivery. This post includes details of the new finishes and the size chart. Each year we make a batch of frames, and since covid, the frames have been selling out in seconds for some sizes, and a day for others. To level the playing field, we are going to host an email raffle in the next two weeks, where you can sign up for a spot to buy a frameset. Check Instagram, Facebook, and here next week for the release date. Shops will receive 3 finishes: Black Rainbow, Matte Phosphate Raw, and Bullitt Green, with a 4th Neon Fade Finish available only at Blue Lug and our raffle at MASH.
We phosphate dip our raw steel frames and finish them with a matte clear. This process slows rust, and is a window into the process of manipulating ancient minerals that make up one of these machines.
We brought back our Bullitt Green finish, this time with a painted rear triangle.
We ED coat all of our painted frames, so steel dropouts won’t rust. It’s small details like this that add up to a thoughtful finished build.
This neon red-purple fade will be available through Blue Lug and MASH exclusively. This Klein inspired long fade has reflective artwork under a gloss clear finish.
The black rainbow finish is quiet in low light, and louder in direct sun.
We cast our own fork crown to offer a classic straight blade lugged fork with a steep rake.
Our steel frames are available in 6 sizes. We label them based on the top tube length measurement center to center. Our frame feels like a classic track bike with nearly matching top and seat tube measurements. Smaller frames will have toe overlap, creating a more aggressive feeling.
This build is shown with 35c dirt tires. The frames are designed to clear most 40c 700c tires, and we’ve seen some fun 650b builds.
Each Steel frame is compatible with front and rear canti or mini v brakes. Each frame includes removable brake studs, seat collar, and top cap assembly, water bottle and brake hole plugs, along with the frame and fork.
Iridescent decals on black rainbow flake
Green Machine

MASH Steel Framesets 2021

Today we are offering batch three of our steel frames. Enclosed are some details, size chart, and links. Check in!

EDIT: This batch sold by 9-14-2020. Next version of these frames will be 5-2021 most likely.
For this batch we made a few updates to a bike we love. Adding a larger 62TT size, Creating our own spec for steel, Electrophoretic Deposition coating to protect dropouts from rusting, and a new head badge for 2021.
Fork ends with new E.D. coating
The green model was inspired by the iconic Mustang driven by Steve McQueen in Bullitt. It has the decaled head badge showing it was the 4th frame designed, but the 7th to be produced.
This is the second batch to use our custom fork crown
Frames and forks have removable brake studs, and replacement bolts
Our geo has always been inspired by classic track frames. Higher bottom bracket, square top tube/seat tube, steep seat and steer tubes. This is what a city bikes feels like to us. Quick, and responsive, while still fun in the dirt.
Shown with 43 Panaracer Gravel SK tires front and rear
Framesets include our 30.0 replaceable collar
We will have a few sets of these custom MASH Phil wheelsets soon.
Heat Treated, double butted, 4130 Steel spec’d for street and dirt
The silver smoke has rainbow flake in it, and really responds in sunlight.

Chas Christiansen 5-2020

Starting to get out and shoot with friends again. No doubt this era of photography will have a unique feel due to its absence of shared space, but also a reminder of what we want to continue to celebrate. Enclosed are some details of Chas Christiansen captured 7:30am to 9am Friday May 8th 2020.
